Thomas Dean

I have wanted to design a scale like cargo hook for sometime. Winter weather gave me the time. The system was tested with a static load of 17.5 pounds as well as a frame test of over 30 pounds. The system is only as strong is it weakest link, however it has not presented itself. Fusion360, Formlabs 4 using Black V5 resin. 1.5mm stranded cable with compression eyelets. Both cargo hooks, upper and lower, are spring loaded allowing the user to snap back the hook into position. The pin used to latch the hook is stainless steel and rolls/compresses the spring until a hole in the hook aligns itself and allows acceptance, thus locking the hook in place. I used a bicycle shift cable to activate the upper hook.

I am wanting to monitor the total mAh used for my turbine batteries and receiver batteries. I also want to utilize the JetiBox emulator in the Jeti transmitter to reset my MUI-30 to 0 mAh after charging.

I have my one MUI-30 sensor programmed to accumulate the mAh and not reset on power cycling, thus giving me a total mAh used. This is working on the test bench using E1, E2 or EXT ports.

In my heli, I have a REX-10 with the following pins used
E1 - Axon
E2 - 900NG for backup
EXT - V-Speak
10 - Turbine
9 - Lights

Is the only way to add more telemetry sensors is to add another REX-x receiver (double path) and use its E1,2 or EXT ports?

I assume the MUI-30 telemetry data can only be collected using ports Ext, E1, E2.
It doesn’t appear a MUI-30 can be plugged into a 900NG backup receiver for logging telemetry data.

What is the method for using several sensors?

I made the switch to Jeti and going thru the learning curve. No doubt I am totally impressed, a whole new world of capabilities with Jeti. The Bell and Lama are converted, waiting on some decent flying to “adjust” the Axon (read Michael and Sandy’s article along with a ton of Sandy’s help). Also, a lot of YouTube learning at Harry Curzon’s pages plus others. I’ve looked at a few other sites, but thought I would post here first. Q: Where is the best place on this site to start a Q&A?
